Femina Digital
Digital mammography system with tomosynthesis for 3D image reconstruction and the possibility of stereo and tomo-biopsies.
Features
- Configurable: FEMINA DIGITAL ISCOCENTRICO 5KW tube 10/16° Focos 0,1/0,3 Motorized vertical displacement AEC filters Detector 24X30 Selenium Collimator 24×30&Ø14cm shovel compression 24×30&12×8 PC Acquisition monitor 2Mpx Dicom 3 screen anti X.
- SMART µPress" COMPRESSION SYSTEM: Based on the specific density of the breast to be examined, the FTSE function automatically adjusts the optimal force to be applied while ensuring minimum discomfort for the patient.
- SENS ROI dual AUTOMATIC exposure with selection of exposure parameters according to the actual density of the breast, using the area of the digital detector or according to the thickness particularly useful for the reliable acquisition of breast images with prostheses.
- FULL FIELD DIRECT CONVERSION DIGITAL DETECTOR available in two versions, both with amorphous selenium and amorphous silicon, which differ in terms of acquisition speed. The pixel resolution of both detectors is only 85μm and is used in both 2D acquisition and tomosynthesis (without binning).
- Multifunction control pedal. Vertical movement of the compression shovel and motorized compression release.
- Keypad and display integrated in the potter bucky: the functions of automatic image labeling, display of rotation angle, compression force, compressed breast thickness and laterality are easily accessible to the operator.
- Remote acquisition station with X-SCREEN SCREEN.
- Display integrated in the unit for X-ray parameter control and image acquisition.
- Management software, acquisition, measurement tools and DICOM compatibility.
- Detector 24×30 in Carbon Fiber.
- Potter Bucky with removable grill and an auxiliary panel with information on C-arm angulation and compression strength and thickness, as well as push buttons to identify the projection to be made.
- Acquisition station integrated in the X-ray bulkhead with high-definition LCD monitor and ergonomic wireless keyboard.
- Management software, acquisition, measurement tools and DICOM compatibility.
- Detector 24×30 Amorphous Selenium.
Acquisition
- Low Dose Fluoroscopy.
- High Quality Fluoroscopy (high quality).
- Digital Radiography (instant image).
- Fluoroscopy in Road Mapping mode (optional).
- Fluoroscopy in DSA mode: Remasking, Subtraction, Landmarking, vascular tracking and stenoisis (optional).
Optional
- Mini-working tower with software for multimodality (FFDM, CR, digitized films, ultrasound, MRI, Tomo) management / image processing and 2D CAD software for mammography FULL DICOM 3.0 MG compatible.
- 2D CAD software for mammography.
- Different diagnostic monitors.
- Various phantoms.
- Prona table for stotaxy.
- Multimodal workstation
- Alma mamo workstation.
Clinical Use
- Diagnosis, screening and localization mammography with needle (Digital Radiographic Breast Imaging).
- Improved radiologic interpretation, particularly in dense sinuses and multifocal lesions, by reducing overlap and enhancing detail.
- It may allow for better breast cancer detection and fewer false positives compared to digital mammography.
- Tomosynthesis, Dual Energy exams, biopsies, stereotaxy or tomo-guided.
Technical Specifications
SID
- Predefined projection position (no.)
- 5 programmable projections (LAT, OBL, CC, OBL, LAT)
- Rotation angle display
- Control Panel and Auxiliary Display
Understanding system
- Blade compression movements
- Motorized and manual fine adjustment (2 tactile wheels)
- Shovel support
- Quick mechanical release
- Maximum clearance available between compression paddle and Potter Bucky
- 325 mm with offset compression blades
- Adjustable compression force range
- From 70 to 200N
- Indicated compression force
- Effective force applied with a resolution of 1N
- Compression vane lowering speed
- 4cm/s at the outlet decreasing proportionally
- Compression force safety device
- Triple: Electronic, electromechanical, mechanical
- Gentle release of compression after exposure
- Selectable from the acquisition station
- Aluminum equivalency of the compression vane
- < 0.2 mm Al (0.135 mm Al≈30 kV)
